Autoclaved Wood Design Fiber Cement Board



Natural Wood Textured Fiber Cement Construction.



WOOD DESIGN SADIKBOARD embodies the perfect fusion of cement and fiber, meticulously designed to replicate the authentic texture of wood while ensuring durability and lasting elegance.

Tailored for both interior and exterior applications, WOOD DESIGN SADIKBOARD offers:



Key Features:

Natural wood texture for timeless elegance. Versatile architectural solutions suitable for a myriad of projects.
Ideal for mechanical installation in ventilated facade systems. Enhances interior spaces with its organic appeal. Lightweight and resilient, ideal for renovation endeavors. Customizable with painting, coating, or wallpapers. Superior impact resistance compared to conventional materials. Functions adeptly as a reliable backer board for cladding materials. Applicable for sheathing floors, roofs, and walls.
Excellent performance in wet spaces as a backer board behind tiles. Simple installation, modification, cutting, and drilling.
Lightweight design facilitates easy handling and transportation. Provides robust protection against various weather conditions. Offers commendable heat and acoustic insulation properties. Resistant to seasonal changes, sunlight, moisture, and water. Environmentally conscious, asbestos-free, and devoid of odors. Impervious to insects, non-putrescible, and mold-resistant.



Applications:





  -Interior:

     Internal walls
     Flooring, including raised and mezzanine floors
     Indoor ceilings
     Wet spaces
     Elevator shaft walls
     Firewalls



  -Exterior:

     External walls and facades
     Roofs
     Outdoor ceilings
     Soffit and fascia
     Fences and boundary walls
     Balconies and parapets

     Noise barriers



Embrace the sophistication and reliability of WOOD DESIGN SADIKBOARD for your construction projects.

Thickness



6 - 18mm / Textured boards 8 - 12mm



Density



1425 kg/m3



Modulus of Elasticity (Moist Condition)



14.3 MPa



Length / Width Tolerance



0.9 millimeters / 0.8 millimeters.



Thickness Tolerance (e: board thickness)



± 0.1 mm / m



Right Angle Deviation



± 0.2mm/m



Edge Smoothness



± %0.1 a:/a: side length



Surface View



Flat or textured



PH Valu



7-8



Acoustic Insulation



STC = 30 dB (6 mm single board)

STC = 50 - 60 dB (10 mm composite wall)



Modulus of Elasticity (Moist Condition)



14.3 MPa



Porosity

%0.3



Bending Strength Ratio after:

Wet-Dry Cycle

Freezing-Thawing Cycle

Immersion in Warm Water





0.87

0.92

0.95

Durability Properties:



 Freeze / Thaw Resistance

 Warm Water Resistance

 Heat / Rain Resistance

 Soak / Dry Resistance



Resistant to freezing according to TS EN 12467



Pass

Pass

Pass

Pass



 Fire Resistance Properties:

 Ignitibility

 Fire Propagation Index

 Surface Spread of Flame

 Reaction to Fire Classification

Combustibility





Pass

I = 0.4

Class 1 

 A1

 Non-Combustible



Asbestos Content



Does not contain asbestos



Other Hazardous Material Emission



Has no hazardous material or gas emission



Size

(MM)

Thickness

(MM)



Weight

(KGS)



Pallet

(PCS)



Loading Quantity

     Per 20GP

   (PCS)



1200x2400

6

24



100



900



1200x2400



8



32



70



675



1200x2400



10



40



60



540



1200x2400



12



48



50



450
